MARATHON 364TTGS16536 HAZLOC MOTOR 60 HP 1780 RPM 230/460V

MARATHON 364TTGS16536 - HAZLOC MOTOR 60 HP 1780 RPM 230/460V - HAZARDOUS LOCATION MOTOR 3-PHASE TOTALLY ENCLOSED FAN-COOLED 60 HP 1780 NAMEPLATE RPM 364T FRAME NEMA DESIGN B CW/CCW ROTATION VOLTAGE 230/460 FULL LOAD AMPS 138/69 PHASE 3 60 HZ RIGID BASE MOUNTING BALL BEARINGS FRAME MATERIAL CAST IRON THERMAL PROTECTION T-STAT SERVICE FACTOR 1.15 HAZARDOUS LOCATION CLASS 1 C D / 2 F G MAX AMBIENT TEMP 40 DEGREES C TEMP CODE T3B SHAFT DIA 2-3/8 IN. SHAFT LENGTH 5-7/8 IN. OVERALL LENGTH 31-1/2 IN. F INSULATION CLASS CONTINUOUS DUTY - EQUAL TO 39P287
