Product Description
DAYTON 3GD49 - SPEED REDUCER C-FACE 56C 40 1 - SPEED REDUCER C-FACE RIGHT ANGLE SHAFT ORIENTATION STANDARD DUTY 1750 INPUT RPM 44 NOMINAL OUTPUT RPM WORM CENTER DISTANCE 2.62 IN. BORE DIA 5/8 IN. 56C FRAME OVERHUNG LOAD 1300 LB. 40 1 NOMINAL RATIO MAX INPUT HP 1 MAX TORQUE 1028 IN.-LB. NUMBER OF STAGES 1 FORWARD/REVERSIBLE ROTATION ANY POSITION EXCEPT INPUT MOTOR SHAFT UP MOUNTING BALL BEARINGS HARDENED STEEL PINION MATERIAL WORM GEAR TYPE CAST IRON HOUSING MATERIAL RIGHT SINGLE OUTPUT OUTPUT SHAFT DIA 1-1/4 IN. - EQUAL TO G2235703
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
3GD49
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
47
CONTRACTOR PART NUMBER:
2510743713
MAS CONTRACT NUMBER:
47QSEA20D0043
