Product Description
DAYTON 4WNZ5 - FARM DUTY MTR,CS,TEAO,3/4 HP,1725 RPM,56 - AGRICULTURAL FAN MOTOR, SINGLE PHASE, MOTOR DESIGN CAPACITOR-START/RUN, 3/4 HP, NAMEPLATE RPM 1,725, NO. OF SPEEDS 1, VOLTAGE 115/208-230V AC, FULL LOAD AMPS 6.1/3.4-3.1, 56 FRAME, 60 HZ, MOTOR SERVICE FACTOR 1.3, MOTOR THERMAL PROTECTION AUTO, INS. CLASS B, MAX. AMBIENT TEMP. 40 DEGREES C, DUTY CYCLE CONTINUOUS, MOTOR SHAFT ROTATION CW/CCW, MOTOR ENCLOSURE DESIGN TOTALLY ENCLOSED AIR-OVER, MOTOR MOUNTING TYPE CRADLE BASE, MOTOR MOUNTING POSITION HORIZONTAL, MOTOR FRAME MATERIAL ROLLED STEEL - EQUAL TO G0993386
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
4WNZ5
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
40.5
CONTRACTOR PART NUMBER:
2510772604
MAS CONTRACT NUMBER:
47QSEA20D0043
