Product Description
E-Z LOK 550-1420 - THREAD INSERT 1/4-20X10.5MM PK5 - SELF LOCKING THREAD INSERT WALL TYPE HEAVY CARBON STEEL INTERNAL THREAD SIZE 1/4-20 EXTERNAL THREAD SIZE M10 X 1.5 THREAD TYPE UNC INTERNAL/METRIC EXTERNAL LENGTH 10.5MM TAP SIZES M10 X 1.5 DRILL SIZE 8.6MM MIN FULL THREAD DEPTH 37/64 EXTERNAL THREAD CLASS 6G INTERNAL THREAD CLASS 2B TENSILE STRENGTH (PSI) 78 300 BRINELL HARDNESS 163 FOR USE ON METAL INSTALLATION SCREWDRIVER BOLT/NUT OR POWER DRIVE TOOL 4ZE54 PACKAGE QUANTITY 5 - EQUAL TO 4ZE65
MANUFACTURER:
E-Z LOK
MANUFACTURER PART NUMBER:
550-1420
UNIT OF MEASURE:
PK
QTY PER UNIT OF MEASURE:
5
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
0.03
CONTRACTOR PART NUMBER:
2510785871
MAS CONTRACT NUMBER:
47QSEA20D0043
