Product Description
MARATHON 145TBDR5345 - MOTOR 2 HP 1740 RPM 115/208-230V NONE - GENERAL PURPOSE MOTOR CAPACITOR-START/RUN OPEN DRIPPROOF 2 HP NAMEPLATE RPM 1740 145T FRAME VOLTAGE 115/208-230 60 HZ 1 PHASE 21.0/11.3-10.5 FULL LOAD AMPS NUMBER OF SPEEDS 1 MOTOR MOUNTING TYPE CRADLE BASE MOTOR MOUNTING POSITION HORIZONTAL MOTOR THERMAL PROTECTION NONE INSULATION CLASS B 1.15 SERVICE FACTOR BALL BEARINGS FRAME MATERIAL ROLLED STEEL MAX AMBIENT TEMP 40 DEGREES C CW/CCW MOTOR SHAFT ROTATION OVERALL LENGTH 14-1/4 IN. MOTOR SHAFT DESIGN KEYED - EQUAL TO G8528886
MANUFACTURER:
MARATHON
MANUFACTURER PART NUMBER:
145TBDR5345
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
50.4
CONTRACTOR PART NUMBER:
2511231292
MAS CONTRACT NUMBER:
47QSEA20D0043
