Product Description
DORIAN 50402 - TURNING TOOLHOLDER SQ. RIGHT SNMG-432 - TURNING TOOLHOLDER SQUARE SHANK FOR USE WITH SNMG-432 INSERTS ANSI 1 NUMBER OF INSERTS REQUIRED NEGATIVE STYLE MULTI-LOCK LOCK CUTTING EDGE TYPE INDEXABLE CARBIDE RAKE NEGATIVE RAKE ANGLE (DEG.) 7 LEFT/RIGHT HAND RIGHT SHANK WIDTH (IN.) 1 SHANK SQUARE SHANK HEIGHT (IN.) 1 OVERALL LENGTH (IN.) 6 INSERT SHAPE SQUARE INSCRIBED CIRCLE (IN.) 0.500 INSERT THICKNESS (IN.) 0.187 CLAMP CL-19 CLAMP SCREW XNS-59 LOCK PIN NL-46 SHIM ISSN-433 - EQUAL TO 33VD89
MANUFACTURER:
DORIAN
MANUFACTURER PART NUMBER:
50402
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
1.75
CONTRACTOR PART NUMBER:
2511259367
MAS CONTRACT NUMBER:
47QSEA20D0043
