DAYTON 36VF77 GP MOTOR TEFC 1/2 HP 1760 RPM 5/8IN DIA.

DAYTON 36VF77 - GP MOTOR TEFC 1/2 HP 1760 RPM 5/8IN DIA. - GENERAL PURPOSE MOTOR 3-PHASE TOTALLY ENCLOSED FAN-COOLED 1/2 HP NAMEPLATE RPM 1760 56C FRAME VOLTAGE 208-230/460 60 HZ 3 PHASE 1.9-1.7/0.86 FULL LOAD AMPS NUMBER OF SPEEDS 1 MOTOR MOUNTING TYPE FACE/BASE MOTOR MOUNTING POSITION HORIZONTAL MOTOR THERMAL PROTECTION NONE INSULATION CLASS F 1.15 SERVICE FACTOR BALL BEARINGS FRAME MATERIAL ROLLED STEEL MAX AMBIENT TEMP 40 DEGREES C CW/CCW MOTOR SHAFT ROTATION OVERALL LENGTH 11-9/16 IN. MOTOR SHAFT DESIGN KEYED - EQUAL TO G0691997
