Product Description
LEESON 100955.00 - LEESON MOTORS-1/3HP, 115/208-230V, 1725RPM, TEFC, RIGID MT, 1.15 SF, 61 EFF - GENERAL PURPOSE, CAPACITOR START-INDUCTOR RUN MOTOR: 1/3HP, 1725 RPM, TOTALLY-ENCLOSED FAN-COOLED (TEFC) ENCLOSURE, 48 FRAME, RIGID MOUNT, 115/208-230V, 1PH, 60HZ, NAME PLATE AMPS 6.6/2.9-3.3, CONTINUOUS DUTY, 1.15 SERVICE FACTOR, NO THERMAL PROTECTION, EFFICIENCY: 61, EFFICIENCY TYPE: STANDARD, AMBIENT 40 C, SELECTIVE CCW ROTATION, SHAFT LENGTH 1-1/2, SHAFT DIAMETER 1/2.
TOTALLY ENCLOSED FAN COOLED (TEFC) ENCLOSURE HAS NO VENT OPENINGS, AND IS TIGHTLY ENCLOSED TO PREVENT THE FREE EXCHANGE OF AIR, BUT IS NOT AIRTIGHT. AN EXTERNAL FAN IS AN INTEGRAL PART OF THE MOTOR AND PROVIDES COOLING BY - EQUAL TO B221754
MANUFACTURER:
LEESON
MANUFACTURER PART NUMBER:
100955.00
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
17
CONTRACTOR PART NUMBER:
2512003801
MAS CONTRACT NUMBER:
47QSEA20D0043
