Product Description
LEESON 140827.00 - WASHDOWN MOTOR 10 HP 3535 RPM - WASHDOWN MOTOR 3-PHASE 10 HP 3535 NAMEPLATE RPM VOLTAGE 230/460 PHASE 3 215TC FRAME TOTALLY ENCLOSED FAN-COOLED FULL LOAD AMPS 23.6/11.8 60/50 HZ MOTOR THERMAL PROTECTION NONE F INS. CLASS MOTOR SERVICE FACTOR 1.15 BALL MOTOR BEARINGS MAX AMBIENT TEMP 40 DEGREES C CW/CCW MOTOR SHAFT ROTATION SHAFT DIA 1-3/8 IN. SHAFT LENGTH 3-1/8 IN. LENGTH LESS SHAFT 15-9/16 IN. MOTOR FRAME MATERIAL STAINLESS STEEL NOMINAL EFFICIENCY 91.5 PERCENT RPM RANGE 3001-3600 - EQUAL TO G4447488
MANUFACTURER:
LEESON
MANUFACTURER PART NUMBER:
140827.00
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
182
CONTRACTOR PART NUMBER:
2512232225
MAS CONTRACT NUMBER:
47QSEA20D0043
