Product Description
JOHNSON CONTROLS VA9208-BAA-3 - ELECTRIC VALVE ACTUATOR ON-OFF 120V - ELECTRIC BALL VALVE ACTUATOR VOLTAGE 120 SIGNAL TYPE ON-OFF TORQUE 70 IN.-LB. CYCLE TIME 55 TO 71 SEC. AMBIENT TEMP RANGE -40 DEGREES TO 140 DEGREES F TYPE OF ACTUATOR SPRING RETURN STROKE DEG. 95 HEIGHT 3-13/32 IN. WIDTH 3-29/32 IN. DEPTH 7-13/32 IN. ELECTRICAL CONNECTIONS CABLE POWER CONSUMPTION 6 VA ENCLOSURE RATING NEMA 2 DIRECT MOUNT MOUNTING FOR USE WITH JCI VG1000 BALL VALVE INCLUDES FACTORY MOUNTED VALVE LINKAGE STANDARDS UL CE C-TICK - EQUAL TO G7045473
MANUFACTURER:
JOHNSON CONTROLS
MANUFACTURER PART NUMBER:
VA9208-BAA-3
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
2.8
CONTRACTOR PART NUMBER:
2510173837
