Product Description
GAST 8AM-FRV-75 - AIR MOTOR 5 HP 175 CFM 2500 RPM - AIR MOTOR 5 HP RUNNING TORQUE @ MAX PRESSURE 132 IN.-LB. 175 CFM MAX AIR FLOW MAX RPM 2500 SHAFT DIA 3/4 IN. SHAFT LENGTH 1.53 IN. FOOT MOUNTING PORT SIZE 1/2 IN NPT REV ROTATION HOUSING MATERIAL CAST IRON GRAY METALLIC FINISH 300 RPM @ MAX TORQUE MAX AIR PRESSURE 100 PSI KEYWAY LENGTH 1.34 IN. OVERALL LENGTH 8.48 IN. OVERALL WIDTH 5.50 IN. OVERALL HEIGHT 6.03 IN. 0 DEGREES TO 250 DEGREES F OPERATING TEMP RANGE INCLUDES MUFFLER - EQUAL TO 6ZC95
MANUFACTURER:
GAST
MANUFACTURER PART NUMBER:
8AM-FRV-75
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
24.55
CONTRACTOR PART NUMBER:
2510180689
MAS CONTRACT NUMBER:
47QSEA20D0043
