MARATHON 182THTY7726 VECTOR MOTOR 9.0 LB-FT 3 HP 230/460 V

MARATHON 182THTY7726 - VECTOR MOTOR 9.0 LB-FT 3 HP 230/460 V - VECTOR MOTOR 3-PHASE TOTALLY ENCLOSED NONVENTILATED 3 HP TORQUE 9.0 LB.-FT. NAMEPLATE RPM 1755 SPEED RANGE 1000 1 CT MAX SPEED 5400 RPM FRAME 182TC MAX OPERATING FREQUENCY 120 HZ VOLTAGE 230/460 60 HZ 3 PHASE 8.4/4.2 FULL LOAD AMPS FACE/BASE MOUNTING ALL ANGLE MOUNTING POSITION CW/CCW ROTATION BALL BEARINGS 1.00 SERVICE FACTOR THERMAL PROTECTION T-STAT INSULATION CLASS F AMBIENT TEMPERATURE 40 DEGREES C NOMINAL EFFICIENCY 0.855 EFFICIENCY GROUP STANDARD NEMA DESIGN A - EQUAL TO G0426221
