MARATHON 256THTNA7026 VECTOR MOTOR 59.5 LB-FT 20 HP 230/460 V

MARATHON 256THTNA7026 - VECTOR MOTOR 59.5 LB-FT 20 HP 230/460 V - VECTOR MOTOR 3-PHASE TOTALLY ENCLOSED NONVENTILATED 20 HP TORQUE 59.5 LB.-FT. NAMEPLATE RPM 1770 SPEED RANGE 1000 1 CT MAX SPEED 4200 RPM FRAME 256TC MAX OPERATING FREQUENCY 120 HZ VOLTAGE 230/460 60 HZ 3 PHASE 52.0/26.0 FULL LOAD AMPS FACE/BASE MOUNTING ALL ANGLE MOUNTING POSITION CW/CCW ROTATION BALL BEARINGS 1.00 SERVICE FACTOR THERMAL PROTECTION T-STAT INSULATION CLASS F AMBIENT TEMPERATURE 40 DEGREES C NOMINAL EFFICIENCY 0.936 EFFICIENCY GROUP PREMIUM NEMA DESIGN A - EQUAL TO G3131265
