MARATHON 56H17T15526 VECTOR MOTOR 1.5 LB-FT 1/2 HP 230/460 V

MARATHON 56H17T15526 - VECTOR MOTOR 1.5 LB-FT 1/2 HP 230/460 V - VECTOR MOTOR 3-PHASE TOTALLY ENCLOSED NONVENTILATED 1/2 HP TORQUE 1.5 LB.-FT. NAMEPLATE RPM 1725 SPEED RANGE 1000 1 CT MAX SPEED 5400 RPM FRAME 56C MAX OPERATING FREQUENCY 120 HZ VOLTAGE 230/460 60 HZ 3 PHASE 1.6/0.8 FULL LOAD AMPS FACE/BASE MOUNTING ALL ANGLE MOUNTING POSITION CW/CCW ROTATION BALL BEARINGS 1.00 SERVICE FACTOR THERMAL PROTECTION NONE INSULATION CLASS H AMBIENT TEMPERATURE 40 DEGREES C NOMINAL EFFICIENCY 0.8 EFFICIENCY GROUP STANDARD NEMA DESIGN A - EQUAL TO 5THZ5
