Product Description
MARATHON 5KCR48TN2174T - MOTOR,3 HP,3,450 RPM,56J,115/230V - GENERAL PURPOSE PUMP MOTOR, SINGLE PHASE, MOTOR DESIGN CAPACITOR-START/RUN, 3 HP, NAMEPLATE RPM 3,450, NO. OF SPEEDS 1, VOLTAGE 115/230V AC, FULL LOAD AMPS 29.4/14.7, 56J FRAME, USABLE @ 208V NO, USABLE @ 200V NO, 60 HZ, MOTOR SERVICE FACTOR 1.15, MOTOR THERMAL PROTECTION AUTO, INS. CLASS B, MAX. AMBIENT TEMP. 40 DEGREES C, DUTY CYCLE CONTINUOUS, MOTOR SHAFT ROTATION CCWSE, MOTOR ENCLOSURE DESIGN OPEN DRIPPROOF, MOTOR MOUNTING TYPE FACE, MOTOR MOUNTING POSITION ALL ANGLE - EQUAL TO G2050711
MANUFACTURER:
MARATHON
MANUFACTURER PART NUMBER:
5KCR48TN2174T
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
38
CONTRACTOR PART NUMBER:
2510279451
MAS CONTRACT NUMBER:
47QSEA20D0043
