Product Description
SQUARE D QOU115 - UNIT MOUNT CIRCUIT BREAKER QOU 1P 15A - UNIT MOUNT CIRCUIT BREAKER CIRCUIT BREAKER TYPE STANDARD NUMBER OF POLES 1 15 AMPS AC VOLTAGE RATING 120/240VAC DC VOLTAGE RATING 48VDC AIR @ 120VAC 10KA AIR @ 240VAC 10KA AIR @ 48VDC 5KA PHASE 1 TERMINAL CONNECTION SLOTTED BOX LUG (REVERSIBLE LINE AND LOAD) SERIES QOU MIN WIRE SIZE 14 AWG MAX WIRE SIZE 2 AWG LENGTH 4.05 IN. WIDTH 0.75 IN. DEPTH 2.98 IN. STANDARDS UL CSA HACR IEC - EQUAL TO G3157917
MANUFACTURER:
SQUARE D
MANUFACTURER PART NUMBER:
QOU115
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
0.3
CONTRACTOR PART NUMBER:
2510459240
MAS CONTRACT NUMBER:
47QSEA20D0043
