MARATHON 184TTFN6555 CT MOTOR 3-PH TEFC 5 HP 230/460V

MARATHON 184TTFN6555 - CT MOTOR 3-PH TEFC 5 HP 230/460V - COOLING TOWER MOTOR 3-PHASE TOTALLY ENCLOSED FAN-COOLED 5 HP 1755 NAMEPLATE RPM 184T FRAME CW/CCW ROTATION 230/460 VOLTAGE 12.4/6.2 FULL LOAD AMPS 3 PHASE 60/50 HZ BASE MOUNTING MOUNTING POSITION HORIZONTAL BEARINGS BALL FRAME MATERIAL CAST IRON NONE THERMAL PROTECTION 1.15 SERVICE FACTOR AMBIENT TEMPERATURE 40 DEGREES C SHAFT DIA 1-1/8 IN. SHAFT LENGTH 2-7/8 IN. LENGTH LESS SHAFT 15 IN. OVERALL LENGTH 17-7/8 IN. INSULATION CLASS F RPM RANGE 1701-1800 DUTY CONTINUOUS - EQUAL TO 19YR40
