Product Description
DAYTON 1AGG2 - MTR CAP ST 1/3 HP 1725 115/208-230V 48Z - BELT DRIVE MOTOR CAPACITOR-START 1/3 HP NAMEPLATE RPM 1725 VOLTAGE 115/208-230 1 PHASE FRAME 48Z OPEN DRIPPROOF FULL LOAD AMPS 5.8/3.1-2.9 60 HZ CRADLE/STUD MOUNTING THERMAL PROTECTION AUTO INSULATION CLASS B SERVICE FACTOR 1.35 BALL BEARINGS MAX AMBIENT TEMP 40 DEGREES C ROTATION CW/CCW OVERALL LENGTH 10-1/4 IN. SHAFT DIA 1/2 IN. SHAFT LENGTH 1-7/8 IN. - EQUAL TO 1AGG2
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
1AGG2
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
16.94
CONTRACTOR PART NUMBER:
2510689276
MAS CONTRACT NUMBER:
47QSEA20D0043
