Product Description
DAYTON 1TRZ2 - WASHDOWN MOTOR 3 PH TENV 1 HP 1725 RPM - WASHDOWN MOTOR 3-PHASE 1 HP 1725 NAMEPLATE RPM VOLTAGE 208-230/460 PHASE 3 143TC FRAME TOTALLY ENCLOSED NONVENTILATED FULL LOAD AMPS 3.3-3.2/1.6 60 HZ FACE/BASE MOUNTING THERMAL PROTECTION NONE F INSULATION CLASS SERVICE FACTOR 1.15 BALL BEARINGS MAX AMBIENT TEMP 40 DEGREES C CW/CCW ROTATION OVERALL LENGTH 11-5/8 IN. SHAFT DIA 7/8 IN. SHAFT LENGTH 2 IN. LENGTH LESS SHAFT 9-5/8 IN. CONTINUOUS DUTY FRAME MATERIAL EPOXY COATED SHAFT MATERIAL 303 STAINLESS STEEL - EQUAL TO 1TRZ2
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
1TRZ2
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
36.6
CONTRACTOR PART NUMBER:
2510690839
MAS CONTRACT NUMBER:
47QSEA20D0043
