Product Description
DAYTON 24PR72 - CONDENSER FAN MOTOR 1 HP 1140 RPM 60HZ - CONDENSER FAN MOTOR MOTOR TYPE 3-PHASE ENCLOSURE OPEN AIR-OVER 1 HP RPM RANGE 1101-1200 NAMEPLATE RPM 1140 VOLTAGE 208-230/460 56YZ FRAME NUMBER OF SPEEDS 1 OVERALL LENGTH 15-3/4 IN. SHAFT LENGTH 5-5/8 IN. SHAFT ORIENTATION UP FEATURES INVERTER DUTY WINDINGS ROTATION CW/CCW FULL LOAD AMPS 4.3-4.3/2.1 BAND MOUNTING THERMAL PROTECTION THERMOSTATS INSULATION CLASS F SERVICE FACTOR 1.00 BEARINGS BALL MAX AMBIENT TEMP 70 DEGREES C SHAFT DIA 5/8 IN. - EQUAL TO 24PR72
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
24PR72
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
32
CONTRACTOR PART NUMBER:
2510710791
MAS CONTRACT NUMBER:
47QSEA20D0043
