MARATHON 286TTFNA7260 CT MOTOR 3-PH TEFC 25 AND 6-1/4 HP

MARATHON 286TTFNA7260 - CT MOTOR 3-PH TEFC 25 AND 6-1/4 HP - COOLING TOWER MOTOR 3-PHASE TOTALLY ENCLOSED FAN-COOLED 25 6-1/4 HP 1775/880 NAMEPLATE RPM 286T FRAME CW/CCW ROTATION 460 VOLTAGE 31/11 FULL LOAD AMPS 3 PHASE 60 HZ BASE MOUNTING MOUNTING POSITION HORIZONTAL BEARINGS BALL FRAME MATERIAL CAST IRON NONE THERMAL PROTECTION 1.15 SERVICE FACTOR AMBIENT TEMPERATURE 40 DEGREES C SHAFT DIA 1-7/8 IN. SHAFT LENGTH 4-13/16 IN. LENGTH LESS SHAFT 22-7/8 IN. OVERALL LENGTH 27-11/16 IN. INSULATION CLASS F RPM RANGE 1701-1800 - EQUAL TO 19YR32
