Product Description
DAYTON 4Z141 - DC MOTOR PM TENV 1/18 HP 1800 RPM 90VDC - DC PERMANENT MAGNET MOTOR PERMANENT MAGNET DC 1/18 HP MOTOR ENCLOSURE DESIGN TOTALLY ENCLOSED NONVENTILATED 1800 NAMEPLATE RPM VOLTAGE 90VDC FULL LOAD AMPS 0.8 FULL LOAD TORQUE 1.95 IN.-LB. FRAME NONSTANDARD MOTOR MOUNTING TYPE FACE/BASE MOTOR THERMAL PROTECTION NONE B INSULATION CLASS BEARINGS BALL MAX AMBIENT TEMP 40 DEGREES C CW/CCW ROTATION OVERALL LENGTH 6-3/8 IN. 4-15/16 IN LENGTH LESS SHAFT SHAFT DIA 1/2 IN. SHAFT LENGTH 1-1/2 IN. BASE MOUNTING O.C. 4-7/16 X 2 IN. - EQUAL TO G1686106
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
4Z141
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
6
CONTRACTOR PART NUMBER:
2510773045
MAS CONTRACT NUMBER:
47QSEA20D0043
