Product Description
DAYTON 5BE66 - MOTOR PSC 1/2 HP 1140 115/230V 56Z OAO - DIRECT DRIVE BLOWER MOTOR PSC MOTOR TYPE OPEN AIR-OVER ENCLOSURE 1/2 HP 1140 NAMEPLATE RPM VOLTAGE 115/230 5.4/2.7 FULL LOAD AMPS 60 HZ 1 PHASE 56Z FRAME SERVICE FACTOR 1.0 MAX AMBIENT TEMP 40 DEGREES C INSULATION CLASS B DUTY CONTINUOUS AIR OVER NUMBER OF SPEEDS 1 MOUNTING STUD SHAFT ORIENTATION ALL ANGLE BEARINGS BALL THERMAL PROTECTION AUTO ROTATION CW/CCW BODY DIA 5-11/16 IN. LENGTH LESS SHAFT 9-27/32 IN. SHAFT DIA 5/8 IN. SHAFT LENGTH 2-3/4 IN. - EQUAL TO G1693781
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
5BE66
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
27.1
CONTRACTOR PART NUMBER:
2510793865
MAS CONTRACT NUMBER:
47QSEA20D0043
