Product Description
DAYTON 5XAT6 - WASHDOWN MOTOR 3 PH TEFC 2 HP 1745 RPM - WASHDOWN MOTOR 3-PHASE 2 HP 1745 NAMEPLATE RPM VOLTAGE 230/460 PHASE 3 145T FRAME TOTALLY ENCLOSED FAN-COOLED FULL LOAD AMPS 5.8/2.9 60/50 HZ BASE MOUNTING THERMAL PROTECTION NONE F INSULATION CLASS SERVICE FACTOR 1.15 BALL BEARINGS MAX AMBIENT TEMP 40 DEGREES C CW/CCW ROTATION OVERALL LENGTH 13-3/4 IN. SHAFT DIA 7/8 IN. SHAFT LENGTH 2-1/4 IN. BODY DIA 6-5/8 IN. LENGTH LESS SHAFT 11-1/2 IN. CONTINUOUS DUTY FRAME MATERIAL EPOXY COATED SHAFT MATERIAL 303 STAINLESS STEEL - EQUAL TO G0280865
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
5XAT6
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
49
CONTRACTOR PART NUMBER:
2510795723
MAS CONTRACT NUMBER:
47QSEA20D0043
