Product Description
MARATHON 145TTDR16330 - MOTOR,1 1/2 HP,1,755 RPM,145JP,230/460V - CLOSE-COUPLED PUMP MOTOR, THREE PHASE, MOTOR DESIGN 3-PHASE, 1 1/2 HP, NAMEPLATE RPM 1,755, NO. OF SPEEDS 1, VOLTAGE 230/460V AC, FULL LOAD AMPS 4.4/2.2, 145JP FRAME, USABLE @ 208V NO, USABLE @ 200V NO, 60/50 HZ, MOTOR SERVICE FACTOR 1.15, MOTOR THERMAL PROTECTION NONE, INS. CLASS F, MAX. AMBIENT TEMP. 40 DEGREES C, DUTY CYCLE CONTINUOUS, NEMA DESIGN B, MOTOR SHAFT ROTATION CW/CCW, MOTOR ENCLOSURE DESIGN OPEN DRIPPROOF, MOTOR MOUNTING TYPE FACE/BASE, MOTOR MOUNTING POSITION HORIZONTAL - EQUAL TO 32UP88
MANUFACTURER:
MARATHON
MANUFACTURER PART NUMBER:
145TTDR16330
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
48
CONTRACTOR PART NUMBER:
2511179261
MAS CONTRACT NUMBER:
47QSEA20D0043
