MARATHON 182TCDW7318 CLOSE-COUPLED PUMP MOTOR3 HP 3500 RPM

MARATHON 182TCDW7318 - CLOSE-COUPLED PUMP MOTOR3 HP 3500 RPM - CLOSE-COUPLED PUMP MOTOR CAPACITOR-START 3 HP NAMEPLATE RPM 3500 VOLTAGE 115/230 1 PHASE FRAME 182JM OPEN DRIPPROOF FULL LOAD AMPS 32.0/16.1 60 HZ FACE/BASE MOTOR MOUNTING TYPE MOTOR THERMAL PROTECTION NONE INSULATION CLASS F SERVICE FACTOR 1.15 BALL BEARINGS MAX AMBIENT TEMP 40 DEGREES C CW/CCW MOTOR SHAFT ROTATION OVERALL LENGTH 15-5/16 IN. SHAFT DIA 7/8 IN. SHAFT LENGTH 4-1/4 IN. FRAME MATERIAL ROLLED STEEL - EQUAL TO G5527042
