EATON FAZ-D5/3 SUPPLEMENTARY PROTECTOR 5A 3P 480VAC

EATON FAZ-D5/3 - SUPPLEMENTARY PROTECTOR 5A 3P 480VAC - SUPPLEMENTARY PROTECTOR AMPS 5 NUMBER OF POLES 3 CURVE TYPE D AC VOLTAGE RATING 277/480VAC DC VOLTAGE RATING 96VDC AIR RATING 10 KA AIR @ 120VAC 10KA AIR @ 125VDC 10KA AIR @ 240VAC 10KA AIR @ 277VAC 10KA AIR @ 480VAC 10KA AIR @ 600VAC 10KA AIR @ 48VDC 10KA AIR @ 65VDC 10KA TRIP TYPE THERMAL MAGNETIC TERMINAL CONNECTION LUG MOUNTING DIN RAIL APPLICATION MOTORS TRANSFORMERS AND POWER SUPPLIES MIN WIRE SIZE 18 AWG MAX WIRE SIZE 4 AWG LENGTH 84.7MM WIDTH 54MM DEPTH 72.6MM - EQUAL TO 19YF62
