DAYTON 36VF90 GP MOTOR TEFC 2 HP 3480 RPM 5/8IN. DIA.

DAYTON 36VF90 - GP MOTOR TEFC 2 HP 3480 RPM 5/8IN. DIA. - GENERAL PURPOSE MOTOR 3-PHASE TOTALLY ENCLOSED FAN-COOLED 2 HP NAMEPLATE RPM 3480 56HC FRAME VOLTAGE 208-230/460 60 HZ 3 PHASE 5.7-5.2/2.6 FULL LOAD AMPS NUMBER OF SPEEDS 1 MOTOR MOUNTING TYPE FACE/BASE MOTOR MOUNTING POSITION HORIZONTAL MOTOR THERMAL PROTECTION NONE INSULATION CLASS F 1.15 SERVICE FACTOR BALL BEARINGS FRAME MATERIAL ROLLED STEEL MAX AMBIENT TEMP 40 DEGREES C CW/CCW MOTOR SHAFT ROTATION OVERALL LENGTH 13-1/8 IN. MOTOR SHAFT DESIGN KEYED - EQUAL TO G0691936
