Product Description
NTN UCFU-1MFG1 - FLANGE BEARING 4-BOLT BALL 1 BORE - FLANGE BEARING STANDARD DUTY WITH FOOD GRADE SOLID LUBRICATION SET SCREW SERIES 1 IN BORE DIA. BALL BEARING INSERT TYPE 52100 CHROME STEEL BEARING INSERT MATERIAL SET SCREW LOCKING TYPE CAST IRON HOUSING MATERIAL NUMBER OF BOLTS 4 BOLT SIZE 7/16 IN. BOLT HOLE CENTER-TO-CENTER 2-3/4 IN. OVERALL HEIGHT 1-17/32 IN. OVERALL WIDTH 3-25/32 IN. OVERALL LENGTH 3-25/32 IN. DYNAMIC LOAD CAPACITY 3150 LB. STATIC LOAD CAPACITY 1 770 LB. TEMP RANGE -10 DEGREES TO 95 DEGREES C - EQUAL TO G9468785
MANUFACTURER:
NTN
MANUFACTURER PART NUMBER:
UCFU-1MFG1
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
JAPAN
ORDER INCREMENT:
1
WEIGHT:
2.1
CONTRACTOR PART NUMBER:
2511676494
MAS CONTRACT NUMBER:
47QSEA20D0043
