MARATHON 254TTTNA17077 KILN MOTOR 3-PH 7.5 HP 1170 RPM 460V

MARATHON 254TTTNA17077 - KILN MOTOR 3-PH 7.5 HP 1170 RPM 460V - KILN MOTOR 3-PHASE TOTALLY ENCLOSED AIR-OVER 7-1/2 HP NAMEPLATE RPM 1170 FRAME 254T VOLTAGE 460 60 HZ 3 PHASE FULL LOAD AMPS 9.8 RIGID BASE MOTOR MOUNTING TYPE THERMAL PROTECTION T-STAT INSULATION CLASS H SERVICE FACTOR 1.15 BALL BEARINGS MAX AMBIENT TEMP 90 DEGREES C MOTOR SHAFT ROTATION CW/CCW SHAFT DIA 1-5/8 IN. SHAFT LENGTH 4-3/16 IN. OVERALL LENGTH 20-5/8 IN. LEAD LENGTH 8 FT. - EQUAL TO 21EN53
