Product Description
SPEEDAIRE 22UX55 - AIR GEARMOTOR 0.32 HP 21 CFM 400 RPM - AIR GEARMOTOR 0.32 HP RUNNING TORQUE @ MAX PRESSURE 49.00 IN.-LB. 21 CFM MAX AIR FLOW NO LOAD RPM 400 SHAFT DIA 1/2 IN. SHAFT LENGTH 1.38 IN. FACE MOUNTING PORT SIZE 1/8 IN NPT REV ROTATION HOUSING MATERIAL CAST IRON GRAY FINISH 40 RPM @ MAX TORQUE GEAR RATIO 15 1 MAX AIR PRESSURE 60 PSI KEYWAY LENGTH 1.38 IN. OVERALL LENGTH 7.35 IN. OVERALL WIDTH 2.93 IN. OVERALL HEIGHT 2.93 IN. 0 DEGREES TO 250 DEGREES F OPERATING TEMP RANGE - EQUAL TO G6176037
MANUFACTURER:
SPEEDAIRE
MANUFACTURER PART NUMBER:
22UX55
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
CHINA
ORDER INCREMENT:
1
WEIGHT:
4.72
CONTRACTOR PART NUMBER:
2512115190
