LEESON 119476.00 WASHDOWN MOTOR 1 HP FACE/BASE 60 HZ CWSE

LEESON 119476.00 - WASHDOWN MOTOR 1 HP FACE/BASE 60 HZ CWSE - WASHDOWN MOTOR 3-PHASE 1 HP 1760 NAMEPLATE RPM VOLTAGE 230/460 PHASE 3 56C FRAME TOTALLY ENCLOSED FAN-COOLED FULL LOAD AMPS 3.2/1.6 60 HZ MOTOR THERMAL PROTECTION NONE F INS. CLASS MOTOR SERVICE FACTOR 1.15 BALL MOTOR BEARINGS MAX AMBIENT TEMP 40 DEGREES C CWSE MOTOR SHAFT ROTATION SHAFT DIA 5/8 IN. SHAFT LENGTH 1-15/16 IN. LENGTH LESS SHAFT 10-15/16 IN. MOTOR FRAME MATERIAL ROLLED STEEL NOMINAL EFFICIENCY 85.5 PERCENT RPM RANGE 1701-1800 - EQUAL TO G4702470
