Product Description
MERSEN STP480Y07 - SURGE PROTECTION DEVICE 480VAC WYE 3PH - SURGE PROTECTION DEVICE VOLTAGE 480VAC WYE PHASE 3 VOLTAGE PROTECTION RATING 2500V (L-L) 1500V (L-N) MAX CONTINUING OPERATING VOLTAGE 320/640 V AC NOMINAL DISCHARGE CURRENT 20KA MODES OF PROTECTION L-L L-N MOUNTING LOCATION INTERNALLY MOUNTED FILTERING NO MODULAR YES AMPS 75K COLOR GRAY MOUNTING STYLE DIN RAIL ENCLOSURE NEMA RATING 1 NUMBER OF POLES 3 BASIC MATERIAL NONMETALLIC NUMBER OF WIRES 4 WIRES SYSTEM CONNECTION PARALLEL MAX SURGE CURRENT PER PHASE 75KA - EQUAL TO 491G70
MANUFACTURER:
MERSEN
MANUFACTURER PART NUMBER:
STP480Y07
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
0.85
CONTRACTOR PART NUMBER:
2512878876
