Product Description
SCHNEIDER ELECTRIC LC1D18BNE - IEC MAGNETIC CONTACTOR,3 POLES - IEC MAGNETIC CONTACTOR, FULL LOAD AMPS-INDUCTIVE 18 A, FULL LOAD AMPS-RESISTIVE 32 A, NUMBER OF POLES 3, COIL VOLTS 24 TO 60 V AC/DC, REVERSING NO, HP @ 1 PHASE - 120V 1 HP, HP @ 1 PHASE - 240V 3 HP, HP @ 3 PHASE - 208V 5 HP, HP @ 3 PHASE - 240V 5 HP, HP @ 3 PHASE - 480V 10 HP, HP @ 3 PHASE - 575V 15 HP, AUX. CONTACT CONFIGURATION 1NO/1NC, ENCLOSURE NEMA RATING NO ENCLOSURE, HZ 50/60, HEIGHT 3.03 IN, WIDTH 1.77 IN, DEPTH 3.38 IN, STANDARDS CSA C22.2, EN 60947-4-1, EN 60947-5-1, UL508 - EQUAL TO 482Z26
MANUFACTURER:
SCHNEIDER ELECTRIC
MANUFACTURER PART NUMBER:
LC1D18BNE
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
FRANCE
ORDER INCREMENT:
1
WEIGHT:
0.9
CONTRACTOR PART NUMBER:
2512910092
