Product Description
US MOTORS 430 - MOTOR,3/4 HP,3450 RPM,48,115/208-230V - BELT DRIVE MOTOR, SINGLE PHASE, MOTOR DESIGN CAPACITOR-START, 3/4 HP, NAMEPLATE RPM 3,450, NO. OF SPEEDS 1, VOLTAGE 115/208-230V AC, 9.2/4.6 FULL LOAD AMPS, 48 FRAME, USABLE @ 208V YES, USABLE @ 200V NO, 60 HZ, MOTOR SERVICE FACTOR 1.25, MOTOR THERMAL PROTECTION AUTO, INS. CLASS B, MAX. AMBIENT TEMP. 104 DEGREES F, DUTY CYCLE CONTINUOUS, MOTOR SHAFT ROTATION CW/CCW, MOTOR ENCLOSURE DESIGN OPEN DRIPPROOF, MOTOR MOUNTING TYPE CRADLE BASE, MOTOR MOUNTING POSITION HORIZONTAL - EQUAL TO G1933210
MANUFACTURER:
US MOTORS
MANUFACTURER PART NUMBER:
430
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
19
CONTRACTOR PART NUMBER:
2513881389
