Product Description
US MOTORS D16B2N4Z9 - MOTOR,1/6 HP,1725 RPM,48Z,115V - HVAC MOTOR, SINGLE PHASE, MOTOR DESIGN SPLIT-PHASE, 1/6 HP, NAMEPLATE RPM 1,725, NO. OF SPEEDS 1, VOLTAGE 115V AC, FULL LOAD AMPS 4.2, 48Z FRAME, USABLE @ 208V NO, USABLE @ 200V NO, MOTOR SERVICE FACTOR 1.4, MOTOR THERMAL PROTECTION NONE, INS. CLASS B, MAX. AMBIENT TEMP. 40 DEGREES C, DUTY CYCLE CONTINUOUS, MOTOR SHAFT ROTATION CW/CCW, MOTOR ENCLOSURE DESIGN OPEN DRIPPROOF, MOTOR MOUNTING TYPE CRADLE BASE, MOTOR MOUNTING POSITION HORIZONTAL, MOTOR FRAME MATERIAL STEEL - EQUAL TO G1932039
MANUFACTURER:
US MOTORS
MANUFACTURER PART NUMBER:
D16B2N4Z9
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
12
CONTRACTOR PART NUMBER:
2513903065
