Product Description
WEG .3318ES3EBMW56-S - WEG ELECTRIC S STANDARD EFFICIENCY AC INDUCTION MOTOR, GENERAL PURPOSE, INVERTER RATED AND BRAKE, 1/3HP, 3-PHASE, 208-230/460 VAC, 1800RPM, TEFC, NEMA 56 FRAME, ROLLED STEEL, RIGID BASE MOUNT. STEARNS 104816100KQ BRAKE ASSEMBLY INCLUDED. - ITEM: MOTOR SERIES: S EFFICIENCY GROUP: STANDARD EFFICIENCY EFFICIENCY: 68 VOLTAGE TYPE: AC MOTOR TYPE: INDUCTION MOTOR APPLICATION: GENERAL PURPOSE, INVERTER RATED AND BRAKE HORSEPOWER RATING: 1/3HP NUMBER OF PHASES: 3 VOLTAGE RATING: 208-230/460 VAC SYNCHRONOUS SPEED: 1800RPM NAMEPLATE RPM: 1730RPM OVERLOAD TYPE: NONE ENCLOSURE TYPE: TEFC SHAFT TYPE: ROUND WITH SQUARE KEY SHAFT DIAMETER: 5/8IN SHAFT MATERIAL: 1045 CARBON STEEL MOTOR FRAME: NEMA 56 FRAME MATERIAL: ROLLED STEEL ELECTRICALLY REVERSIBLE: YES INSULATION CLASS: CLASS F IP RATING: IP55 CONSTANT TORQUE RATING: - EQUAL TO .3318ES3EBMW56-S
MANUFACTURER:
WEG
MANUFACTURER PART NUMBER:
.3318ES3EBMW56-S
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
25.54
CONTRACTOR PART NUMBER:
2702082913
