Product Description
DAYTON 2CNL2 - LINEAR BALL BEARING,OPEN,BORE 1 IN - BORE DIA. (IN.) 1.000, INSIDE DIA. TOLERANCE +/-.0004, OUTSIDE DIA. (IN.) 1.5625, OUTSIDE DIA. TOLERANCE +/-0.00065, SLOT WIDTH (IN.) 0.563 IN, SLOT WIDTH (MM) -, SLOT ANGLE (DEGREES) 50 DEGREES , RETENTION HOLE DIA. (MM) -, RETENTION HOLE LOCATION 0.125, BETWEEN GROOVES (MM) -, LENGTH (IN.) 2.25 IN, LENGTH (MM) -, STATIC LOAD CAPACITY (LB.) 1,050 LB, MAX. PV -, TEMP. RANGE (F) 0 - 176, STAINLESS STEEL/POLYMER CAGE MATERIAL, LOAD CAPACITY (LBF.) -, REQUIRED HOUSING BORE DIA. (IN.) - - EQUAL TO G3338063
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
2CNL2
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
CHINA
ORDER INCREMENT:
1
WEIGHT:
0.25
CONTRACTOR PART NUMBER:
2510720052
