Product Description
DAYTON 5RHU0 - BLOWER MOTOR 1/6 TO 1/3 HP 825 RPM 60 HZ - DIRECT DRIVE BLOWER MOTOR PERMANENT SPLIT CAPACITOR MOTOR DESIGN OPEN AIR-OVER MOTOR ENCLOSURE DESIGN 1/3 TO 1/6 HP 825 NAMEPLATE RPM VOLTAGE 208-230 2.2 FULL LOAD AMPS 60 HZ 1 PHASE 48YZ FRAME MOTOR SERVICE FACTOR 1.00 MAX AMBIENT TEMP 60 DEGREES C INS. CLASS B DUTY CONTINUOUS NO OF SPEEDS 4 MOTOR MOUNTING TYPE STUD MOTOR MOUNTING POSITION ALL ANGLE MOTOR BEARINGS BALL MOTOR THERMAL PROTECTION AUTO MOTOR SHAFT ROTATION CW/CCW LENGTH LESS SHAFT 6 IN. OVERALL LENGTH 11 IN. - EQUAL TO G2735704
MANUFACTURER:
DAYTON
MANUFACTURER PART NUMBER:
5RHU0
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
ORDER INCREMENT:
1
WEIGHT:
16.45
CONTRACTOR PART NUMBER:
2511382406
