Product Description
LEESON 112547.00 - MOTOR,1/3 HP,1725,56C,208-230/460V - WASHDOWN MOTOR, THREE PHASE, MOTOR DESIGN 3-PHASE, 1/3 HP, NAMEPLATE RPM 1,725, NO. OF SPEEDS 1, VOLTAGE 208-230/460V AC, FULL LOAD AMPS 1.70-1.50/0.85, 56C FRAME, USABLE @ 208V YES, USABLE @ 200V NO, 60 HZ, MOTOR SERVICE FACTOR 1.2, MOTOR THERMAL PROTECTION MANUAL, INS. CLASS F, MAX. AMBIENT TEMP. 104 DEGREES F, DUTY CYCLE CONTINUOUS, NEMA DESIGN B, REMOVABLE BASE NO, MOTOR SHAFT ROTATION CW/CCW, MOTOR ENCLOSURE DESIGN TOTALLY ENCLOSED FAN-COOLED, MOTOR MOUNTING TYPE FACE/BASE - EQUAL TO G400722974
MANUFACTURER:
LEESON
MANUFACTURER PART NUMBER:
112547.00
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
UNITED STATES OF AMERICA
ORDER INCREMENT:
1
WEIGHT:
27
CONTRACTOR PART NUMBER:
2514352985
