Product Description
US MOTORS 1195 - MOTOR 1/2HP 1140RPM 115/230V 60HZ 48Y - MOTOR SINGLE PHASE MOTOR DESIGN PERMANENT SPLIT CAPACITOR 1/2 HP NAMEPLATE RPM 1 140 NO OF SPEEDS 1 VOLTAGE 115/230V AC FULL LOAD AMPS 5.8/2.8 A 48Y FRAME 60 HZ HZ MOTOR THERMAL PROTECTION AUTO INS. CLASS B MAX AMBIENT TEMP 40 DEGREES C MOTOR SHAFT ROTATION CCW MOTOR ENCLOSURE DESIGN TOTALLY ENCLOSED AIR-OVER SHAFT DIA 1/2 IN SHAFT LENGTH 4 1/2 IN MOTOR SHAFT DESIGN KEYED OVERALL LENGTH 12 15/16 IN LENGTH LESS SHAFT 8 7/16 IN WEIGHT 19.43 LB - EQUAL TO 617F92
MANUFACTURER:
US MOTORS
MANUFACTURER PART NUMBER:
1195
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
MEXICO
ORDER INCREMENT:
1
WEIGHT:
19.43
CONTRACTOR PART NUMBER:
2516909410
