Product Description
SIMPLEX RAC603 - 60 TON S/A C/H ALUM. 3'' STROKE CYL. - CYLINDER, SINGLE ACTING, CENTER HOLE, ALUMINUM, NOMINAL CAPACITY 60 TON, MAX. PUSH CAPACITY 60 TON, STROKE LENGTH 3 IN, NOMINAL STROKE LENGTH 3 IN, EFFECTIVE PUSH AREA 12.3 SQ IN, MAX. PRESSURE 10,000 PSI, OIL CAPACITY PUSH 37 CU IN, RETRACTED HEIGHT 10.13 IN, EXTENDED HEIGHT 13.13 IN, OUTSIDE DIA. 7.5 IN, PLUNGER DIA. NOT APPLICABLE, PLUNGER THREAD SIZE NA0-8 UNC- 2B, CENTER HOLE DIA. 2.13 IN, WEIGHT 42 LB, INCLUDES RETURN SPRING, BORE DIA. NOT APPLICABLE - EQUAL TO G412655703
MANUFACTURER:
SIMPLEX
MANUFACTURER PART NUMBER:
RAC603
UNIT OF MEASURE:
EA
QTY PER UNIT OF MEASURE:
1
COUNTRY OF ORIGIN:
CANADA
ORDER INCREMENT:
1
WEIGHT:
46.05
CONTRACTOR PART NUMBER:
2518228906
